Product Details:
Payment & Shipping Terms:
|
| Alloy Or Not: | Alloy | Standard: | AiSi, ASTM, Bs, DIN, GB, JIS |
|---|---|---|---|
| Diameter: | 4-100mm | Length: | 4-6m Or As Your Requirment |
| High Light:: | Hot Rolled Steel Bar | Type: | Spring Steel |
| High Light: | 100Cr6 Hot Rolled Steel Bars,6m Length Hot Rolled Steel Bars,Astm Round Spring Steel |
||
Bearing ring ,steel rolling mill ,machinery, 100Cr6 bearing steel ball is widely used in high-speed and low-noise bearing, bicycle, motorcycle, automobile,bags, electronical Machine parts, engineering components 100Cr6 is a kind of common steel which is used to produce balls and rings of bearing. The product has characteristics of uniform-chemical composition, low percentage of harmful elements, high purity, well-distributed carbide, good surface quality. It also has characteristics of wide scope of plastic, stable heat-treatment quality, uniformed high hardness, high wear resistance , high strength of touching fatigue. It has excellent machining property afer spheroidize annealing.
| Material | 52100/GCr15/100Cr6/SUJ2 | ||
| Chemical Composition | Mechanical Properties(In Quenched & Tempered State) | ||
| C | 0.95-1.05 | Tensile strength(MPA) | ---- |
| Si | 0.15-0.35 | Yield strength (MPA) | -- |
| Mn | 0.25-0.45 | Elongation(δ5/%) | -- |
| Cr | 1.40-1.65 | Reduction in Area (ψ/%) | -- |
| Mo | ≤0.10 | Impact (J) | -- |
| P | ≤0.025 |
Hardness |
HB170-207 HB207-229 HB270-390 HB229-285 HRC62-66 HRC61-66 HRC≈67 |
| S | ≤0.025 | ||
| Ni | ≤0.30 | ||
| Cu | ≤0.25 | ||
| Ni+Cu | ≤0.50 | ||
Competitive Advantage:
High wearing-resisting property
Good hardenability
High resistance to thermal properties.
Competitive price
Fast production leadtime
All the material are inspected with 3 times to meet the highly standards
Production Inspection
Our heat treatment center with complete product testing equipment, for instance: the scanning electron micro sconezz(SEM).the transmission electron microscope(TEM)the material testing machine. the large-type metallurgical microscope,the endurance testing machine,the IAS-4 image analyzer, the American ARL direct- reading spectrometer, the American the electric ICP emission spectrometer, the American LECO infrared carbon sulfur analyzer, the hydrogen analyzer, the oxygen and nitrogen analyzer,the Swiss end harden ability tester, the German Zeiss inverted microscope, the Japanese CARTON stereo microscope, the 500J impact testing machine, the 500N hydraulic universal tester, the water immersion flaw detector, the radio element detector and so on.
Evergrowing aim:
Competitive price: try best to make best offer
Top quality: 100% comply with customer's standard
JIT delivery: Delivery on time for each order.
One station purchase:we try to supply the material with different condition to our customers.
After service: Response on any quality question and etc.
