Product Details:
Payment & Shipping Terms:
|
| Length: | 50-6000mm | Standard: | ASTM B348 |
|---|---|---|---|
| Grade: | Gr1-GR12 | Product Name: | Polished 8mm ASTM B348 Grade 5 Titanium Round Bar |
| Shape: | Round | Material: | GR5 |
| High Light: | ASTM B348 Standard Titanium Round Bar,Medical Equipment Gr5 Titanium Round Bar,500mm Titanium Alloy Bars |
||
ASTM B348 Standard Specification for Titanium and Titanium Alloy Bars and Billets. Because of its high strength and lightweight property, they are widely used in the component for the high-temperature environment, including aircraft equipment, petrochemical and chemical industry and so on.
| Specifications Chart | ASTM B348/ ASTM SB348 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size in mm | 5 mm To 500 mm |
| Diameter in mm | 0.1 mm to 100 mm |
| Length in mm | 100 mm To 3000 mm Long & Above |
| Surface Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
Product Description
Chemical Composition:
| Grade | N | C | H | Fe | O | AI | V | Pa | Mo | Ni | Ti |
|
Gr1 |
0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | / | / | Bal |
|
Gr2 |
0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | / | / | Bal |
|
Gr3 |
0.05 | 0.08 | 0.015 | 0.35 | 0.35 | / | / | / | / | / | Bal |
|
Gr4 |
0.05 | 0.08 | 0.015 | 0.4 | 0.4 | / | / | / | / | / | Bal |
|
Gr5 |
0.05 | 0.08 | 0.015 | 0.5 | 0.2 | 5.5-6.75 | 3.4-4.5 | / | / | / | Bal |
|
Gr7 |
0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0.12-0.25 | / | / | Bal |
|
Gr9 |
0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5-3.5 | 2.0-3.0 | / | / | / | Bal |
|
Gr12 |
0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | 0.2-0.4 | 0.6-0.9 | Bal |
Mechinal property:
| Material | Tensile strength MPa | elongation % | Resuction of Area % |
| GR1 | ≥240 | ≥24 | ≥30 |
| GR2 | ≥400 | ≥20 | ≥30 |
| GR3 | ≥500 | ≥18 | ≥30 |
| GR4 | ≥580 | ≥15 | ≥25 |
| GR5 | ≥895 | ≥10 | ≥25 |
| GR5ELI | ≥825 | ≥8 | ≥15 |
FAQ
1. Who are we?
We are based in Jiangsu, China, start from 2019,sell to Western Europe(30.00%),Africa(20.00%),Northern Europe(20.00%),Domestic Market(10.00%),North America(5.00%),South America(5.00%),Southeast Asia(5.00%),South Asia(5.00%). There are total about 5-10 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Rolled bar in peeled,Rolled bar in black skin,Forged steel round bar,Forged steel square bar,Tool steel bar
4. Why should you buy from us not from other suppliers?
We are top agent of several different steel mills in Asia and Europe,so we have ability to offer best quality products and services to our clients.We have international technology.
