Product Details:
Payment & Shipping Terms:
|
| Shape: | Round.Square.etc | Special Use: | Free Cutting Steel |
|---|---|---|---|
| Technique: | Cold Forming | Grade: | Q235/Q235B/Q345/Q345B/SS400 |
| Material: | Cold Darwn Steel | Product Name: | Channel Steel Profile |
| Thickness: | 2.5mm | Application: | Construction, Industry ,vehicle Manufacturing |
| High Light: | Evergrowrs U Channel Rolled Steel Sections,Evergrowrs U Channel Rolled Steel Section,Evergrowrs U Channel 2.5mm Hollow Square Steel Tube |
||
Building Materials Steel U Channel 2.5mm Thickness Rolled Steel Sections
Specifications of Rolled Steel Sections
|
Product Name
|
Channel Steel
|
|
Standard
|
ASTM,BS,GB,JIS,etc
|
|
Grade
|
SS400, ST37-2, A36, S235JRG1, Q235, Q345 etc
|
|
Specification
|
5#-40#
|
|
Thickness
|
2.5mm
|
|
Length
|
6m, 9m, 12m or as customized
|
|
Surface treatment
|
Hot Dip Gavalnized / Black / Painted
|
|
Zinc coating
|
30-90um
|
|
Packing
|
In bundles
|
|
SPECIFICATION
|
SIZE
|
KG/M
|
|
5#
|
50*37*4.5
|
5.438
|
|
6.3#
|
63*40*4.8
|
6.634
|
|
8#
|
80*43*5.0
|
8.045
|
|
10#
|
100*48*5.3
|
10.007
|
|
12#
|
120*53*5.5
|
12.059
|
|
14#A
|
140*58*6.0
|
14.535
|
|
14#B
|
140*60*8.0
|
16.733
|
|
16#A
|
160*63*6.5
|
17.24
|
|
16#B
|
160*65*8.5
|
19.752
|
|
18#A
|
180*68*7.0
|
20.174
|
|
18#B
|
180*70*9.0
|
23
|
|
20#A
|
200*73*7.0
|
22.337
|
|
20#B
|
200*75*9.0
|
25.777
|
|
22#A
|
220*77*7.0
|
24.999
|
|
22#B
|
220*79*9.0
|
28.453
|
|
25#A
|
250*78*7.0
|
27.41
|
|
25#B
|
250*80*9.0
|
31.335
|
|
25#C
|
250*82*11.0
|
35.26
|
|
28#A
|
280*82*7.5
|
31.427
|
|
28#B
|
280*84*9.5
|
35.823
|
|
28#C
|
280*86*11.5
|
40.219
|
|
30#A
|
300*85*7.5
|
34.463
|
|
30#B
|
300*87*9.5
|
39.173
|
|
30#C
|
300*89*11.5
|
43.883
|
|
32#A
|
320*88*8.0
|
38.083
|
|
32#B
|
320*90*10.0
|
43.107
|
|
32#C
|
320*92*12.0
|
48.131
|
|
36#A
|
360*96*9.0
|
47.814
|
|
36#B
|
360*98*11.0
|
53.466
|
|
36#C
|
360*100*13.0
|
59.118
|
|
40#A
|
400*100*10.5
|
58.928
|
|
40#B
|
400*102*12.5
|
65.204
|
|
40#C
|
400*104*14.5
|
71.488
|
Our Related Products
Product Processing
Production Inspection
Our heat treatment center with complete product testing equipment, for instance: the scanning electron micro sconezz(SEM).the transmission electron microscope(TEM)the material testing machine. the large-type metallurgical microscope,the endurance testing machine,the IAS-4 image analyzer, the American ARL direct- reading spectrometer, the American the electric ICP emission spectrometer, the American LECO infrared carbon sulfur analyzer, the hydrogen analyzer, the oxygen and nitrogen analyzer,the Swiss end harden ability tester, the German Zeiss inverted microscope, the Japanese CARTON stereo microscope, the 500J impact testing machine, the 500N hydraulic universal tester, the water immersion flaw detector, the radio element detector and so on.
Evergrowing aim:
Competitive price: try best to make best offer
Top quality: 100% comply with customer's standard
JIT delivery: Delivery on time for each order.
One station purchase:we try to supply the material with different condition to our customers.
After service: Response on any quality question and etc.
