Mild SS400 16mm Structural Steel Plates Primitive Surface

China Evergrowing Resources Co., Ltd. certification
I'm Online Chat Now

Mild SS400 16mm Structural Steel Plates Primitive Surface

Mild SS400 16mm Structural Steel Plates Primitive Surface
Mild SS400 16mm Structural Steel Plates Primitive Surface Mild SS400 16mm Structural Steel Plates Primitive Surface

Large Image :  Mild SS400 16mm Structural Steel Plates Primitive Surface

Product Details:
Place of Origin: China
Brand Name: Evergrowrs
Certification: ISO ,etc.
Model Number: As per standard
Payment & Shipping Terms:
Minimum Order Quantity: 5 Tons
Price: 300-1000 USD/Ton
Packaging Details: Seaworthy package
Delivery Time: 40-50 Days
Payment Terms: D/A, D/P, T/T, L/C, Western Union
Supply Ability: 5000 Tons per Month
Detailed Product Description
Surface Treatment: Coated,primitive Standard: AISI,DIN,JIS,GB,ASTM
Technique: Cold Rolled, Hot Rolled Application: Ship Plate
Grade: Ss400 Dimension: 20x1500x6000mm
Certificate: ISO9001:2008 Product Name: Stainless Steel Steel Plate
High Light:

16mm Structural Steel Plates


SS400 Structural Steel Plates


iso hot roll plate

Mild SS400 Steel Plate 16mm Thickness Primitive Surface Structural Steel Plates
Structural Steel Plates Composition:

Brand Grade C≤ Mn≤ Si≤ P≤ S≤
SS400 A 0.22 1.4 0.3 0.045 0.45
B 0.20 0.045 0.045
C 0.17 0.040 0.040
D 0.17 0.035 0.035


Brand Grade Yield point σs,MPa

Tensile strength





Longitudinal impact strengt,AkV,J(℃)

180°Bending test

d=Diameter of apex

a=Specimen thickness

≤16 >16-35 >35-100 20 0 -20 -40
No less than No less than ≤16 >16
SS400 A 235 225 215 375-500 18         2a 3a
B 235 225 215 375-500 18 34       2a 3a
C 235 225 215 375-500 19   34     2a 3a
D 235 225 215 375-500 19     34   2a 3a
A steel plate is a flat sheet made of molten steel poured, cooled, and pressed. It is flat, rectangular and can be rolled directly or cut from a wide strip of steel. According to the thickness of steel plate, thin steel plate <4 mm (the thinest 0.2 mm), medium thick steel plate 4~60 mm, extra thick steel plate 60~115 mm. The steel plate is divided by rolling, hot rolled and cold rolled. The width of the sheet is 500~1500 mm; The width of the thickness is 600~3000 mm. There are ordinary steel, high quality steel, alloy steel, spring steel, stainless steel, tool steel, heat-resistant steel, bearing steel, silicon steel and industrial pure iron sheet, etc. According to the professional use, there are oil drum board, enamel board, bulletproof board; According to the surface coating, there are galvanized sheet, tin plate, lead plate, plastic composite steel plate.

Steel Plate Process Flow
Mild SS400 16mm Structural Steel Plates Primitive Surface 0
Structural Steel Plates Inspection
Our heat treatment center with complete product testing equipment, for instance: the scanning electron micro sconezz(SEM).the transmission electron microscope(TEM)the material testing machine. the large-type metallurgical microscope,the endurance testing machine,the IAS-4 image analyzer, the American ARL direct- reading spectrometer, the American the electric ICP emission spectrometer, the American LECO infrared carbon sulfur analyzer, the hydrogen analyzer, the oxygen and nitrogen analyzer,the Swiss end harden ability tester, the German Zeiss inverted microscope, the Japanese CARTON stereo microscope, the 500J impact testing machine, the 500N hydraulic universal tester, the water immersion flaw detector, the radio element detector and so on.
Structural Steel Plates Packing and Delivery
Mild SS400 16mm Structural Steel Plates Primitive Surface 1Mild SS400 16mm Structural Steel Plates Primitive Surface 2
About Us
Evergrowing Resources Co.,Limited was set up on 2016 whichLocated on HK,China. Evergrowing has engaged in import and export of all kinds of iron and steel materials all over the world.Because we are topagent of several different steel mills in Asia and Europe,so we have ability to offer best quality products and services to our clients.Till now, we have supplied products and servicesin Asia, Europe, Africa and South America.
Following the trend of market development, Evergrowing has built our specialsteel processing center in Jiangsu, China to do further processing on the products,such as heat treatment (QT, N,ANN),rough turned,cutting and etc.Evergrowing has extended its industrial train andenhanced the ability to provide the auxiliary item, and thus has strengthened its market advantage.
