Product Details:
Payment & Shipping Terms:
|
| Shape: | Steel Round Bar | Alloy Or Not: | Not |
|---|---|---|---|
| Transport Package: | Nude Packing Or As Requested | Cutting:: | Four Edges Cutted |
| Standard: | API, ASTM, API 5L, ASTM | Model NO.: | Steel Round Bar |
| Diameter: | 10-350mm | ||
| High Light: | 4cr13 Stainless Steel Round Bar,Antirust Steel Round Bar |
||
Description
| Type: | Alloy Steel Bar |
| Standard: | AISI, ASTM, GB, JIS, DIN, BS |
| Technique: | Hot Rolled |
| Application: | Tool Steel Bar, Die Steel Bar |
| Surface Treatment: | Polished |
| Alloy: | Alloy |
Basic Info.
Model NO.:1.2083/SUS420J2/420/4Cr13
Special Use:Mold Steel
Heat Treatment:Annealing +Q+T
Cutting:Four Edges Cutted
Test:SGS / Ut 100% / Element Testing
Grade:1.2083, S136,420ss,4Cr13
Delivery Quatity:Include MOQ
Payment:30% Deposit,Blance by L/C at Sight or T/T
Transport Package:Export Standard Packing or Customers′demand
Specification:diameter 10-350mm
Origin:Jiangsu,China
Product Description
1.2083 mould steel is a kind of plastic mould steel with high chromium element which is up to 13%.1.2083mould steel has good wear resistance and good polishing, it widely used for acid proof plastic mold.
Similar grade:DIN 1.2083 AISI 420 JIS SUS420J2
Chemical Composition(%)
|
Steel Grade
|
Chemical Composition(%) |
|||||
|
C |
Si | Mn | P | S | Cr | |
| 1.2083 |
0.36-0.42
|
≤1.00 | ≤1.00 | ≤0.030 | ≤0.030 | 12.50-13.50 |
|
SUS420J2
|
0.26-0.35 | ≤1.00 | ≤1.00 | ≤0.035 | ≤0.030 | 12.00-14.00 |
|
420
|
0.26-0.40 | ≤1.00 | ≤1.00 | ≤0.040 | ≤0.030 | 12.00-14.00 |
|
S136
|
0.38 | 0.9 | 0.5 | ≤0.040 | ≤0.030 | 13.6 |
|
4Cr13
|
0.36-0.45 | ≤0.60 | ≤0.80 | ≤0.035 | ≤0.030 | 12.00-14.00 |
Availabe Sizes (mm):
| Grade |
Size(mm)
|
||
| 1.2083 Plate | Thickness | Width(mm) |
Length
|
| 6-195 | 2200 |
5800
|
|
| 1.2083 Round Bar |
Diameter
|
Length | |
|
10-350
|
3000-6000 | ||
Recommend heat treatment:
|
Heating temperature/℃
|
Cooling way |
Hardness(HRC)
|
Temoering temperature /℃ |
Hardness(HRC) | |
|
Preheating temperature
|
Solution temperature |
||||
|
920-980 |
1050-1100 |
oil Coling
|
48-54 | 200 | ≥48 |
Features
1. Highly quality of corrosion resistance
2. Pre-hardened delivery save forming mould time
3. Good anti-rusty capacity and easy for welding
4. Excellent polish ability and wear-resisting with high toughness
5. Convenient heat treatment for quenched&tempered steel, without deformed
Application
1. Transparent plastic mould
2. Highly stressed cutting and punching tools for thin sheets
3. Stone processing tools and knives for paper and plastics,shear knives
4. Requiring higher food industrial equipment parts and PVC / PP / EP
