ASTM Structural Steel Plates

China Evergrowing Resources Co., Ltd. certification
I'm Online Chat Now

ASTM Structural Steel Plates

ASTM Structural Steel Plates
ASTM Structural Steel Plates ASTM Structural Steel Plates

Large Image :  ASTM Structural Steel Plates

Product Details:
Place of Origin: China
Brand Name: Evergrowrs
Certification: ISO ,etc.
Model Number: As per standard
Payment & Shipping Terms:
Minimum Order Quantity: 5 Tons
Price: 300-1000 USD/Ton
Packaging Details: Seaworthy package
Delivery Time: 10-20 Days
Payment Terms: D/A, D/P, T/T, L/C, Western Union
Supply Ability: 5000 Tons per Month
Detailed Product Description
Surface Treatment: Coated Standard: AISI,DIN,JIS,GB,ASTM
Technique: Hot Rolled Shape: Flat Sheet
Product Name: Carbon Steel Plate Width: 100-4000mm
Certificate: ISO9001:2008 Product Name: Hot Rolled Steel Plate
High Light:

ASTM Structural Steel Plates


4000mm Structural Steel Plates


Coated mild steel flat plate

ASTM A283 GRC A285 MS Plate ISO9001:2008 Structural Steel Plates


Standard Grade C max Mn max Si max P S Yield strength max Tensile strength Elongation%
JISG3101 SS400 0.22 - 0.30 0.045 0.030 245 400-500 26
GB700 Q235B 0.14-0.22 0.30-0.65 0.30 0.045 0.030 235 375-460 21-26
ASTM A36 0.24 - 0.40 0.045 0.030 250 400-52 26


Grade SS400,Q235B,A36
Technique Hot rolled
Thickness 2.0mm-500mm
Width 1250mm,1500mm,1800mm,2000mm
Length Customer's Requirement
Packing Bundle packed by steel strip, or as per request
Application Construction,mechine,building,container manufacture,shipping building,
bridge and other field
A steel plate is a flat sheet made of molten steel poured, cooled, and pressed. It is flat, rectangular and can be rolled directly or cut from a wide strip of steel. According to the thickness of steel plate, thin steel plate <4 mm (the thinest 0.2 mm), medium thick steel plate 4~60 mm, extra thick steel plate 60~115 mm. The steel plate is divided by rolling, hot rolled and cold rolled. The width of the sheet is 500~1500 mm; The width of the thickness is 600~3000 mm. There are ordinary steel, high quality steel, alloy steel, spring steel, stainless steel, tool steel, heat-resistant steel, bearing steel, silicon steel and industrial pure iron sheet, etc. According to the professional use, there are oil drum board, enamel board, bulletproof board; According to the surface coating, there are galvanized sheet, tin plate, lead plate, plastic composite steel plate.

Steel Plate Process Flow

ASTM Structural Steel Plates 0


Structural Steel Plates Inspection

Our heat treatment center with complete product testing equipment, for instance: the scanning electron micro sconezz(SEM).the transmission electron microscope(TEM)the material testing machine. the large-type metallurgical microscope,the endurance testing machine,the IAS-4 image analyzer, the American ARL direct- reading spectrometer, the American the electric ICP emission spectrometer, the American LECO infrared carbon sulfur analyzer, the hydrogen analyzer, the oxygen and nitrogen analyzer,the Swiss end harden ability tester, the German Zeiss inverted microscope, the Japanese CARTON stereo microscope, the 500J impact testing machine, the 500N hydraulic universal tester, the water immersion flaw detector, the radio element detector and so on.


Structural Steel Plates Packing and Delivery

ASTM Structural Steel Plates 1ASTM Structural Steel Plates 2


About Us

Evergrowing Resources Co.,Limited was set up on 2016 whichLocated on HK,China. Evergrowing has engaged in import and export of all kinds of iron and steel materials all over the world.Because we are topagent of several different steel mills in Asia and Europe,so we have ability to offer best quality products and services to our clients.Till now, we have supplied products and servicesin Asia, Europe, Africa and South America.

Following the trend of market development, Evergrowing has built our specialsteel processing center in Jiangsu, China to do further processing on the products,such as heat treatment (QT, N,ANN),rough turned,cutting and etc.Evergrowing has extended its industrial train andenhanced the ability to provide the auxiliary item, and thus has strengthened its market advantage.


Evergrowing aim:

Competitive price: try best to make best offer

Top quality: 100% comply with customer's standard

IT delivery: Delivery on time for each order.

One station purchase:

we try to supply the material with different condition to our customers.

After service: Response on any quality question and etc.
